Home » Catalogue » Hand Rail Fittings / Clamp On Fittings
Hand Rail Fittings / Clamp On Fittings
Manufacturers in India of Handrail Fittings / Clamp On Fittings including Railing clamps which are used for handrails ; safety guardrails , Fencing and other allied jobs by jointing pipes / Tubes used in scaffolding and construction works.
The Fittings come under our brand name KM Klamps which are manufactured at our sophisticated production unit by utilizing optimum quality raw materials and pioneering technology in compliance with international quality standards. In addition to this, all our Klamp / Clamp Fittings are of excellent finish both in Galvanized and Powder coated Clamp and other related specifications at lowest prices.
Features of the KM Klamp Fitting
1. Galvanized cast iron or Powder Coated as Required by Customer. 2. Quick and easy installation 3. No welding 4. Installation by Allen Key . 5. Higher Tensile Strength upto 35350 LBS. 6. Higher Tensile Strength Ensures No Cracking. 7. Flexible systems for various applications. 8. Excellent finish and rugged design 9. Manufactured using pristine quality raw materials 10. Rigid structure and compact design
Specifications of the KM Klamp Fitting
MATERIAL CONFORMATION - BS EN 1562:1997
- GALVANIZING STANDARDS - EN 1461 : 199
- TENSILE STRENGTH - 35350 LBS
- TYPE OF SET SCREWS - STAINLESS STEEL
-
Single Socket Tee
Product Code - HRF-101
DESCRIPTION A 27 B 34 C 42 D 48 E 60 PIPE SIZE (INCHES) 3/4" 1" 1-1/4" 1-1/2" 2" PIPE SIZE (METRIC) 26.9 33.7 42.4 48.3 60.3 -
4 - Way Elbow
Product Code - HRF-116
DESCRIPTION A 27 B 34 C 42 D 48 E 60 PIPE SIZE (INCHES) 3/4" 1" 1-1/4" 1-1/2" 2" PIPE SIZE (METRIC) 26.9 33.7 42.4 48.3 60.3 -
Elbow
Product Code - HRF-125
DESCRIPTION A 27 B 34 C 42 D 48 E 60 PIPE SIZE (INCHES) 3/4" 1" 1-1/4" 1-1/2" 2" PIPE SIZE (METRIC) 26.9 33.7 42.4 48.3 60.3 -
Base Flange
Product Code - HRF-131
DESCRIPTION A 27 B 34 C 42 D 48 E 60 PIPE SIZE (INCHES) 3/4" 1" 1-1/4" 1-1/2" 2" PIPE SIZE (METRIC) 26.9 33.7 42.4 48.3 60.3 -
Plastic Caps
Product Code - HRF-133
DESCRIPTION A 27 B 34 C 42 D 48 E 60 PIPE SIZE (INCHES) 3/4" 1" 1-1/4" 1-1/2" 2" PIPE SIZE (METRIC) 26.9 33.7 42.4 48.3 60.3 -
Wall Bracket
Product Code - HRF-143
DESCRIPTION A 27 B 34 C 42 D 48 E 60 PIPE SIZE (INCHES) 3/4" 1" 1-1/4" 1-1/2" 2" PIPE SIZE (METRIC) 26.9 33.7 42.4 48.3 60.3 -
Swivel Tee
Product Code - HRF-148
DESCRIPTION A 27 B 34 C 42 D 48 E 60 PIPE SIZE (INCHES) 3/4" 1" 1-1/4" 1-1/2" 2" PIPE SIZE (METRIC) 26.9 33.7 42.4 48.3 60.3 -
Base Flange (0° - 11°)
Product Code - HRF-152
DESCRIPTION A 27 B 34 C 42 D 48 E 60 PIPE SIZE (INCHES) 3/4" 1" 1-1/4" 1-1/2" 2" PIPE SIZE (METRIC) 26.9 33.7 42.4 48.3 60.3 -
Elbow (0° - 11°)
Product Code - HRF-154
DESCRIPTION A 27 B 34 C 42 D 48 E 60 PIPE SIZE (INCHES) 3/4" 1" 1-1/4" 1-1/2" 2" PIPE SIZE (METRIC) 26.9 33.7 42.4 48.3 60.3 -
Cross (0° - 11°)
Product Code - HRF-156
DESCRIPTION A 27 B 34 C 42 D 48 E 60 PIPE SIZE (INCHES) 3/4" 1" 1-1/4" 1-1/2" 2" PIPE SIZE (METRIC) 26.9 33.7 42.4 48.3 60.3 -
Clamp-On Crossover
Product Code - HRF-160
DESCRIPTION A 27 B 34 C 42 D 48 E 60 PIPE SIZE (INCHES) 3/4" 1" 1-1/4" 1-1/2" 2" PIPE SIZE (METRIC) 26.9 33.7 42.4 48.3 60.3 -
Combination Socket
Product Code - HRF-165
DESCRIPTION A 27 B 34 C 42 D 48 E 60 PIPE SIZE (INCHES) 3/4" 1" 1-1/4" 1-1/2" 2" PIPE SIZE (METRIC) 26.9 33.7 42.4 48.3 60.3 -
Double Swivel Connection
Product Code - HRF-167
DESCRIPTION A 27 B 34 C 42 D 48 E 60 PIPE SIZE (INCHES) 3/4" 1" 1-1/4" 1-1/2" 2" PIPE SIZE (METRIC) 26.9 33.7 42.4 48.3 60.3 -
Wall Plate Swivel
Product Code - HRF-169
DESCRIPTION A 27 B 34 C 42 D 48 E 60 PIPE SIZE (INCHES) 3/4" 1" 1-1/4" 1-1/2" 2" PIPE SIZE (METRIC) 26.9 33.7 42.4 48.3 60.3 -
Double Mesh Clips
Product Code - HRF-171
DESCRIPTION A 27 B 34 C 42 D 48 E 60 PIPE SIZE (INCHES) 3/4" 1" 1-1/4" 1-1/2" 2" PIPE SIZE (METRIC) 26.9 33.7 42.4 48.3 60.3 -
Lug Short Tee With Swivel Connection
Product Code - HRF-174
DESCRIPTION A 27 B 34 C 42 D 48 E 60 PIPE SIZE (INCHES) 3/4" 1" 1-1/4" 1-1/2" 2" PIPE SIZE (METRIC) 26.9 33.7 42.4 48.3 60.3 -
Side Outlet Tee
Product Code - HRF-176
DESCRIPTION A 27 B 34 C 42 D 48 E 60 PIPE SIZE (INCHES) 3/4" 1" 1-1/4" 1-1/2" 2" PIPE SIZE (METRIC) 26.9 33.7 42.4 48.3 60.3
-
Long Tee
Product Code - HRF-104
DESCRIPTION A 27 B 34 C 42 D 48 E 60 PIPE SIZE (INCHES) 3/4" 1" 1-1/4" 1-1/2" 2" PIPE SIZE (METRIC) 26.9 33.7 42.4 48.3 60.3 -
Cross
Product Code - HRF-119
DESCRIPTION A 27 B 34 C 42 D 48 E 60 PIPE SIZE (INCHES) 3/4" 1" 1-1/4" 1-1/2" 2" PIPE SIZE (METRIC) 26.9 33.7 42.4 48.3 60.3 -
3 Way Elbow
Product Code - HRF-128
DESCRIPTION A 27 B 34 C 42 D 48 E 60 PIPE SIZE (INCHES) 3/4" 1" 1-1/4" 1-1/2" 2" PIPE SIZE (METRIC) 26.9 33.7 42.4 48.3 60.3 -
Raining Base Flange
Product Code - HRF-132
DESCRIPTION A 27 B 34 C 42 D 48 E 60 PIPE SIZE (INCHES) 3/4" 1" 1-1/4" 1-1/2" 2" PIPE SIZE (METRIC) 26.9 33.7 42.4 48.3 60.3 -
Gate Hinge Pin
Product Code - HRF-140
DESCRIPTION A 27 B 34 C 42 D 48 E 60 PIPE SIZE (INCHES) 3/4" 1" 1-1/4" 1-1/2" 2" PIPE SIZE (METRIC) 26.9 33.7 42.4 48.3 60.3 -
Side Palm
Product Code - HRF-146
DESCRIPTION A 27 B 34 C 42 D 48 E 60 PIPE SIZE (INCHES) 3/4" 1" 1-1/4" 1-1/2" 2" PIPE SIZE (METRIC) 26.9 33.7 42.4 48.3 60.3 -
Socket
Product Code - HRF-149
DESCRIPTION A 27 B 34 C 42 D 48 E 60 PIPE SIZE (INCHES) 3/4" 1" 1-1/4" 1-1/2" 2" PIPE SIZE (METRIC) 26.9 33.7 42.4 48.3 60.3 -
Short Tee (0° - 11°)
Product Code - HRF-153
DESCRIPTION A 27 B 34 C 42 D 48 E 60 PIPE SIZE (INCHES) 3/4" 1" 1-1/4" 1-1/2" 2" PIPE SIZE (METRIC) 26.9 33.7 42.4 48.3 60.3 -
Long Tee (0° - 11°)
Product Code - HRF-155
DESCRIPTION A 27 B 34 C 42 D 48 E 60 PIPE SIZE (INCHES) 3/4" 1" 1-1/4" 1-1/2" 2" PIPE SIZE (METRIC) 26.9 33.7 42.4 48.3 60.3 -
4 Way Cross
Product Code - HRF-158
DESCRIPTION A 27 B 34 C 42 D 48 E 60 PIPE SIZE (INCHES) 3/4" 1" 1-1/4" 1-1/2" 2" PIPE SIZE (METRIC) 26.9 33.7 42.4 48.3 60.3 -
Crossover
Product Code - HRF-161
DESCRIPTION A 27 B 34 C 42 D 48 E 60 PIPE SIZE (INCHES) 3/4" 1" 1-1/4" 1-1/2" 2" PIPE SIZE (METRIC) 26.9 33.7 42.4 48.3 60.3 -
Inline Swivel
Product Code - HRF-166
DESCRIPTION A 27 B 34 C 42 D 48 E 60 PIPE SIZE (INCHES) 3/4" 1" 1-1/4" 1-1/2" 2" PIPE SIZE (METRIC) 26.9 33.7 42.4 48.3 60.3 -
90° Corner Swivel Combination
Product Code - HRF-168
DESCRIPTION A 27 B 34 C 42 D 48 E 60 PIPE SIZE (INCHES) 3/4" 1" 1-1/4" 1-1/2" 2" PIPE SIZE (METRIC) 26.9 33.7 42.4 48.3 60.3 -
Single Mesh Clips
Product Code - HRF-170
DESCRIPTION A 27 B 34 C 42 D 48 E 60 PIPE SIZE (INCHES) 3/4" 1" 1-1/4" 1-1/2" 2" PIPE SIZE (METRIC) 26.9 33.7 42.4 48.3 60.3 -
Single Swivel Connection
Product Code - HRF-173
DESCRIPTION A 27 B 34 C 42 D 48 E 60 PIPE SIZE (INCHES) 3/4" 1" 1-1/4" 1-1/2" 2" PIPE SIZE (METRIC) 26.9 33.7 42.4 48.3 60.3 -
Lug Elbow With Swivel Connection
Product Code - HRF-175
DESCRIPTION A 27 B 34 C 42 D 48 E 60 PIPE SIZE (INCHES) 3/4" 1" 1-1/4" 1-1/2" 2" PIPE SIZE (METRIC) 26.9 33.7 42.4 48.3 60.3
- MATERIAL CONFORMATION - BS EN 1562:1997
- GALVANIZING STANDARDS - EN 1461 : 199
- TENSILE STRENGTH - 32510 LBS
- TYPE OF SET SCREWS - STAINLESS STEEL
